Supplements & spare parts

We are happy to offer below components either to extend your metallurgical process control system or to replace components that have been well used.



Production unit (art no 240002)

Wall-mounted hardware for process control using ATAS MetStar software.

Components:
• Industrial panel PC with WLAN
• Industrial keyboard with trackball
• Measuring box
• UPS
• Steel Housing

Option:
• Control unit

Dimensions, cm:
L: 60 W: 60 D:21 (additional 20cm for keyboard)

Viewer unit (art no 240003)

Wall-mounted hardware for process control using ATAS MetStar software.

Components:
• Industrial panel PC with WLAN
• Industrial keyboard with trackball
• UPS
• Steel Housing

Dimensions, cm:
L: 60 W: 60 D:21 (additional 20cm for keyboard)

Portable unit (art no 240004)

Hardware for process control using ATAS MetStar software.

Components:
• Measuring box
• USB cable
• Hard case
• One (1) small twin sampling station

Dimensions, cm:
L: 33,9 W: 29,5 D:15,2

Weight, kg:
4,5

Single sampling station (art no 241001)

Components:
• One (1) single cup holder, upper part
• One (1) cup holder, lower part
• One (1) contact device for sample cups
• Five (5) meter shielded cable for each contact device

Twin sampling station (art no 241002)

Components:
• One (1) single cup holder, upper part
• One (1) cup holder, lower part
• Two (2) contact devices for sample cups
• Five (5) meter shielded cable for each contact device

Small twin sampling station (art no 249002)

Designed for the portable ATAS MetStar unit.

Components:
• One (1) cup holder box
• Two (2) towers
• Two (2) contact devices for sample cups
• Two (2) meter shielded cable for each contact device

Measuring unit/AD converter (art no 242001)

Components:
• Measuring box
• Handle
• USB cable
• Power supply cable

Control unit I/0 (art no 243001)

To regulate signal unit and other external devices.

Components:
• Control box
• USB cable
• Power supply cable

Signal unit/lamp set (art no 243002)

Components:
• Lamp post red/yellow/green
• Ten (10) meter signal cable

Calibration instrument (art no 249001)

The calibrator in the Calibration kit (art no 240006).

Calibration contact head (art no 2490010)

The calibration contact head with compensation cable in the Calibration kit (art no 240006).

Cup contact device, type-K (art no 249003)

Compensation cable, shielded, type-K (art no 249004)

Connector, male, type-K (art no 249007)

Standard connection for new installation.

Connector, female, type-K (art no 249008)

Standard connection for new installation.

Panel jack, 3-pole, type-K (art no 249009)

Standard connection for new installation.

Signal cable (art no 249010)

Supplementary cable for the Signal unit (art no 243002).
Connector, male (art no 249011)
Connector, female (art no 249012)

Communication device (art no 249042)

RKC Com-K2-1.
